Hire of Fluke FiberInspector Mini for 1 Week

One-Week Rental: Fluke FI-500 FiberInspector™ Micro Fibre Optic Scope Camera

The FI-500 FiberInspector™ Micro from Fluke is an advanced fibre optic inspection camera designed to simplify and enhance the process of inspecting and verifying fibre end faces. Its innovative features provide precise results with minimal effort, even in challenging environments.

Dirty or damaged fibre optic end faces are a leading cause of issues in single-mode and multimode fibre optic systems. The FI-500 is equipped to overcome these challenges, offering quick and clear inspections in tight, low-light conditions. With the touch of a button, the autofocus functionality delivers a sharp image of the fibre end face in just seconds. Additionally, the freeze-frame feature allows you to pause the image for steady viewing in hard-to-reach locations.

The built-in PortBright™ flashlight provides illumination for dark and crowded panels, ensuring the probe can be positioned with ease. A large display screen showcases end faces for both single-mode and multimode fibres, and the kit includes four UPC tips (LC, SC, 1.25 mm, and 2.50 mm), with additional APC and bulkhead tips available as optional extras.

Highlighted Features

• PortBright™ Illumination: The integrated flashlight on the probe illuminates densely packed fibre panels, making it easier to locate ports without the need for a separate light source. The PortBright light is activated via a button on the probe.
• Compact Probe Design: The probe’s slim design—23mm wide and 51mm thick—allows for easy access to tight spaces without disturbing nearby fibres, making it ideal for high-density panels.
• Autofocus for Quick, Stable Results: With the push of a button, the FI-500 autofocuses on UPC end faces within 3-5 seconds, delivering clear and stable images. It can also autofocus on APC end faces, though some manual adjustments may be needed for optimal alignment.
• Autocenter Feature: Once the image is paused, the autocenter function ensures that the fibre ferrule is perfectly centred on the display, allowing for straightforward inspection of the fibre core without additional adjustments.
• Versatile Tip Options: The FI-500 comes with four standard UPC tips (LC, SC, 1.25 mm, and 2.50 mm) and supports optional APC and bulkhead tips for added flexibility in different inspection scenarios.
